High-Output LED Modules – Custom LED Module Manufacturer
What is an LED Linear Module?
An LED linear module is a rigid or semi-rigid lighting unit that integrates multiple LEDs on a linear PCB, designed to deliver uniform light output across defined areas.
Compared to flexible LED strip lights, linear modules offer improved thermal management, more stable installation, and consistent optical performance, making them suitable for professional lighting applications.
How Do LED Linear Modules Work?
LED linear modules operate as complete lighting systems where LED chips, PCB layout, thermal design, and power input work together to produce stable and efficient illumination.
The overall performance depends not only on the LEDs themselves, but also on how effectively heat is managed and how evenly light is distributed across the module.
Zhaga-Standard LED Module
Our modular LED lights and SMD module LED are high-efficiency LED light sources pre-mounted on durable PCBs. They deliver uniform brightness, superior efficacy, and a long operating life. Built to Zhaga standards, these replaceable LED modules ensure cross-brand compatibility, quick LED module lighting integration, and minimal maintenance—perfect for both OEM and ODM applications.
Commonly used in office lighting, retail displays, and architectural fixtures, our LED module lights and modular LED light strips help reduce R&D costs, accelerate production, and deliver consistent optical results. Choose standardized, modular LED lights for dependable, high-performance lighting projects.
140x24mm 550lm Modular LED Light Module
Model: ROX24T012E-140MM/RQX24T012E-140MM
Input Voltage: 10.4-11.4VDC
Input Current: 275mA
Input Watt: 3W
Lumens: 549-621 lm
Luminous Efficacy: 183-205 lm/W
LED Types: SMD3030/SMD2835
LED Chip: Samsung/Osram/LUMILEDS/Bridgelux/Seoul
LED QTY: 12pcs
Color Temperature: 2700K/3000K/4000K/5000K/6500K
CRI: 80/90
Dimension: 139×23.6×1.6mm
PCB Material: Aluminum/FR-4
Certification: CE, RoHS
Warranty: 5 Years
280x24mm 1100lm LED Light Module
Model: ROX24T024E-280MM/RQX24T024E-280MM
Input Voltage: 20.9-22.7VDC
Input Current: 275mA
Input Watt: 6.1W
Lumens: 1098-1241 lm
Luminous Efficacy: 183-205 lm/W
LED Types: SMD3030/SMD2835
LED Chip: Samsung/Osram/LUMILEDS/Bridgelux/Seoul
LED QTY: 24pcs
Color Temperature: 2700K/3000K/4000K/5000K/6500K
CRI: 80/90
Dimension: 279×23.6×1.6mm
PCB Material: Aluminum/FR-4
Certification: CE, RoHS
Warranty: 5 Years
560x24mm 2200lm SMD Module LED
Model: ROX24T048E-560MM/RQX24T048E-560MM
Input Voltage: 41.8-45.4VDC
Input Current: 275mA
Input Watt: 12.1W
Lumens: 2195-2482 lm
Luminous Efficacy: 183-205 lm/W
LED Types: SMD3030/SMD2835
LED Chip: Samsung/Osram/LUMILEDS/Bridgelux/Seoul
LED QTY: 48pcs
Color Temperature: 2700K/3000K/4000K/5000K/6500K
CRI: 80/90
Dimension: 559×23.6×1.6mm
PCB Material: Aluminum/FR-4
Certification: CE, RoHS
Warranty: 5 Years
1120x24mm 4500lm LED Module Lighting
Model: ROX24T096E-1120MM/RQX24T096E-1120MM
Input Voltage: 83.6-90.8VDC
Input Current: 275mA
Input Watt: 24.3W
Lumens: 4491-4964 lm
Luminous Efficacy: 187-205 lm/W
LED Types: SMD3030/SMD2835
LED Chip: Samsung/Osram/LUMILEDS/Bridgelux/Seoul
LED QTY: 96pcs
Color Temperature: 2700K/3000K/4000K/5000K/6500K
CRI: 80/90
Dimension: 1119×23.6×1.6mm
PCB Material: Aluminum/FR-4
Certification: CE, RoHS
Warranty: 5 Years
Where Are LED Light Modules Used
LED light modules are not just for new lighting projects—they are also designed to replace outdated light sources in traditional fixtures.
By upgrading old fluorescent, LED troffer or conventional LED tubes with standardized Zhaga-compatible LED modules, you can improve energy efficiency, extend lifespan, and achieve more consistent light output without redesigning the entire luminaire.
Therefore, the application scope of LED module lights spans office lighting, retail supermarkets, industrial sectors, and linear fixtures for educational spaces, extending to warehouses, logistics centers, parking lots, and buildings.
Choose SignliteLED’s modular LED lights for the most flexible and efficient OEM/ODM lighting solutions on the market.
Custom Modular LED Light Solutions
SignliteLED offers complete customization for LED modular lights—from electrical performance to board dimensions. Whether you need tailored lengths, special CCTs, or unique mounting designs, our modular LED light solutions meet your exact project requirements.
LED Brands Available:Choose from renowned LED chips, including Samsung, Osram, Lumileds, Bridgelux, Seoul, Nichia, Cree, and more, to enhance luminous efficacy, color consistency, and lifespan.
Constant Current / Constant Voltage Design: Offers customizable constant current or constant voltage solutions compatible with various driver systems, ensuring stable brightness and system compatibility.
DOB (Driver-on-Board) Customization: Offers DOB options—integrating drivers onto modules to simplify fixture design and save space and costs, ideal for retrofit projects; supports corresponding thermal management and certification requirements.
Board & Substrate Structure: Choose Aluminum PCB for enhanced heat dissipation or FR-4 for cost reduction.
Terminal & Connector Brands: Reliable terminal/connector solutions compatible with WAGO, MOLEX, JST, and others, ensuring easy plug-and-play, vibration resistance, and high assembly efficiency.
Module Form Factor Customization: From rigid to flexible, linear to area modules—we customize circuit boards in any shape to fit diverse fixture forms and dimensions.
Free Design Service
Free design services to reduce development costs.
Flexible Customization
Constant current/constant voltage solutions to meet diverse project requirements.
10–15 Days Delivery
Quick response to shorten project cycles.
Global Certification Assurance
Compliant with international standards including CE, UL, RoHS, ETL, and more.
Customer-Customized Product Performance Testing
Every LED linear module we deliver is tested and verified as a complete system, ensuring reliable performance beyond individual component specifications. Real-world results depend on the interaction between LEDs, PCB design, thermal management, and driving conditions—this is where our validation focuses.
Through integrating sphere testing and system-level measurement, we confirm actual luminous output, system efficacy, and electrical stability under real operating conditions.
Each module is engineered to maintain stable output, controlled temperature rise, and uniform illumination, making it suitable for demanding applications such as signage, architectural lighting, and backlighting systems.
Full test data and project-specific validation support are available upon request.
Item | LED Type | Serial and Parallel Mode | Number of LEDs | Voltage | Typ. Forward Current | Power | Flux | Efficiency | CCT | Ra | Download |
|---|---|---|---|---|---|---|---|---|---|---|---|
280×18mm | SMD2835 | 4S5P | 20pcs | 11.05VDC | 450mA | 4.971W | 1005 lm | 202.07 lm/W | 3966K | 82.7 | Test Report |
493×24mm | SMD2835 | 20S1P | 20pcs | 59.75VDC | 125mA | 8.3W | 1335 lm | 160.8 lm/W | 2990K | 82.8 | Test Report |
493×50mm | SMD2835 | 20S3P | 60pcs | 55.5VDC | 350mA | 21.6W | 3712 lm | 175.96 lm/W | 2993K | 82.7 | Test Report |
560×18mm | SMD2835 | 8S5P | 40pcs | 22.2VDC | 400mA | 10.2W | 1663 lm | 162.58 lm/W | 3967K | 83 | Test Report |
560×18mm | SMD2835 | 8S5P | 40pcs | 22.2VDC | 275mA | 10.2W | 2517 lm | 178.5 lm/W | 5970K | 82.4 | Test Report |
560×18mm | SMD2835 | 8S6P | 48pcs | 21.86VDC | 275mA | 8.7W | 1736 lm | 198.61 lm/W | 5970K | 82.4 | Test Report |
560×18mm | SMD5630 | 8S6P | 48pcs | 22.1VDC | 400mA | 8.84W | 1825 lm | 206.43 lm/W | 4872K | 83.1 | Test Report |
560×20mm | SMD2835 | 16S3P | 48pcs | 33.6VDC | 350mA | 11.8W | 2248 lm | 190.54 lm/W | 3956K | 83 | Test Report |
1120×18mm | SMD2835 | 16S5P | 80pcs | 46VDC | 350mA | 17.9W | 3254 lm | 182.29 lm/W | 3914K | 82.8 | Test Report |
Playlist
LED Module Lighting Compatibility & Accessories
Our LED linear modules integrate seamlessly with DALI, 0–10V, and Casambi control systems, supporting dimming and smart lighting. We also supply compatible drivers, connectors, and mounting clips—ensuring modular LED light setups are reliable, efficient, and easy to install.
This provides smooth integration and maximum design flexibility for OEM luminaire manufacturers.
Model: EM FIT 18/40/60/75 220-240 D CS L G2
Input Voltage: AC220-240V
Output Voltage: DC25-54V/DC40-120V/DC90-175V/DC90-216V
Output Current: 200-350mA/350-550mA
Power: 18W/40W/60W/75W
Efficicency: 87%-92%
PF: >0.96
IP Rating: IP20
Certification: CE, ENEC, CCC, RCM, TISI, BIS
Warranty: 5 years
Model: LC 35W/40W/50W/60W/75W/112W flexC lp SNC4
Input Voltage: AC220-240V
Output Voltage: DC176-280V
Output Current: 200-350mA/350-500mA
Power: 35W/40W/50W/60W/75W/112W
Efficicency: 90%-94%
PF: >0.95
IP rating: IP20
Certification: CE, ENEC, CCC
Warranty: 5 years
Model: LF-FMR020YSIII/LF-FMR040YSIII/LF-FMR060YSIII
Input Voltage: AC220-240V
Output Voltage: DC25-75V/DC40-130V/DC80-200V
Output Current: 200/250/300/350mA
Power: 20W/40W/60W
Efficicency: 87%-92.5%
PF: ≥0.93
IP Rating: IP20
Certification: ENEC, CE, CB, UKCA, RCM, EL, CCC, EAC
Warranty: 5 years
Compared to LED Linear Module vs LED Strip Light
While LED strip lights are flexible and easy to install, LED linear modules provide superior structural stability, thermal management, and long-term reliability. Linear modules are typically preferred in professional and commercial applications where consistent performance is critical, while LED strips are more suitable for decorative or space-constrained installations. Learn more about LED Linear Modules vs. LED Strip Lights.
Key Differences:
Rigid & Flexibility: LED strips use flexible circuit boards for easy bending and shaping, whereas linear modules are rigid and built for structural stability and durability.
Installation Method: LED strips feature adhesive backing for quick installation, while linear modules are mounted using screws, clips, or connectors for more secure and permanent setups.
Heat Management & Lifespan: Linear modules offer better heat dissipation due to their rigid PCB design, resulting in improved stability and longer operational lifespan.
Applications: Linear modules are widely used in signage, lightboxes, and architectural lighting where uniform illumination is required, while LED strips are more commonly used for decorative lighting, accent lighting, or confined spaces.
Customization: LED strips can be cut at defined intervals for flexible length adjustment, while linear modules are typically fixed in size but can be connected for scalable configurations.
Why Choose Our Zhaga LED Modules
Zhaga Standard
Compatible with global luminaire designs, making modules LED quick and easy to replace.
High Output
Up to 11,000 lm, providing superior brightness at lower power consumption.
Long Lifespan
LM-80 tested, exceeding 50,000 hours for dependable LED lighting modules.
CCT Options
Available from 2700K–6500K with CRI 80/90+, ideal for modular LED lighting applications.
Uniform Light Output
Optimized PCB design enables uniform illumination even with small package distance.
Easy Installation
Push terminals simplify wiring from one LED module to LED module, improving assembly speed.
How to Wire LED Module Lights
SignliteLED’s LED module lights are not equipped with overvoltage, overcurrent, overload, or short-circuit current protection. Therefore, they must be used with LED drivers compliant with relevant standards to ensure safe and reliable operation.
⚠️ Our linear LED light modules are designed for series wiring and must be powered by constant-current LED drivers. Using constant-voltage LED drivers will cause irreversible damage to the modules.
How to Install Modular LED Lights
For most applications of LED module, screw-fastening is recommended to ensure a reliable thermal connection between the modular LED lights and the heat dissipation surface.
Additionally, the actual heat dissipation area may vary due to material properties, structural shape, external influences, and installation conditions. Depending on the specific characteristics of the heat sink, thermal paste or thermal double-sided tape may be required to reduce the module’s surface temperature.
The following installation steps are based on linear lighting fixtures.
Related Blog
FAQs About LED Linear Modules
This section provides clear and concise answers to frequently asked questions about LED linear modules, including their structure, applications, performance factors, and differences from LED strip lights.
It is intended as a quick reference for understanding how LED linear modules are used in real-world lighting applications.
An LED linear module is a rigid lighting unit that integrates multiple LEDs on a linear PCB to provide uniform and stable illumination for applications such as signage and backlighting.
LED linear modules are rigid and designed for stable, high-performance lighting, while LED strips are flexible and better suited for decorative or space-limited applications.
LED linear modules are generally better for professional applications requiring consistent brightness, durability, and thermal stability, while LED strips are more suitable for flexible and decorative uses.
LED linear modules are widely used in lightboxes, channel letters, retail displays, and architectural backlighting where uniform illumination is required.
LED linear modules provide even light distribution, reduce hotspots, and maintain stable brightness, making them ideal for signage and display lighting.
Yes, LED linear modules can be customized in terms of length, power, LED type, PCB design, and optical performance to meet specific project requirements.
Performance depends on factors such as LED quality, PCB design, heat dissipation, and driving conditions, not just the LED specifications alone.
The lifespan of LED linear modules depends on thermal management and operating conditions, but high-quality modules can typically operate for tens of thousands of hours.
Uniform lighting is achieved through optimized LED spacing, optical design, and proper installation within the lighting system.
Yes, many linear modules are designed to be linked together for extended lengths and scalable lighting systems.
Some LED linear modules are designed for outdoor use, but this depends on waterproofing, enclosure design, and environmental protection.
Choosing the right module depends on application requirements, including brightness, installation method, thermal conditions, and overall system design.
